Metal: Drywall Vent Flush Double Channel [Luxe+]

White Satin

4″x10″
4″x12″
6″x10″
6″x12″
6″x14″
8″x8″
10″x10″
10″x14.25″
10″x30.25″
12″x12″

High-performance, ultra-minimal flush drywall vent with a double air channel for enhanced airflow. Designed with a drywall bead for a seamless finish, leaving only dual rectangular air channels visible post-installation.

Installation: Must be installed during the drywalling stage; professional installation required. Larger sizes may need joist notching.
Airflow: Full control with a sliding tray to adjust built-in dampers.
Easy to Clean: Slide and remove tray for easy duct cleaning.
Increased Air Flow: Provides 40%-100% more airflow compared to single-channel models (size dependent). Examples:
10"x14": 47% increase in open area vs. standard model.
10"x30": 50% increase in open area vs. standard model.

100% manufactured in Canada. For drywall surfaces only.

See detailed dimensions here.

Size	Open Free Area	Detailed Specs
4"x10"	19.7 sq.in.	CFM, SP
4"x12"	23.7 sq.in.	CFM, SP
6"x10"	23.6 sq.in.	CFM, SP
6"x12"	27.1 sq.in.	CFM, SP
6"x14"	30.6 sq.in.	CFM, SP
8"x8"	30.2 sq.in.	CFM, SP
10"x10"	41.6 sq.in.	CFM, SP
10"x14.25"	57.5 sq.in.	CFM, SP
10"x30.25"	94.1 sq.in.	CFM, SP
12"x12"	53.8 sq.in.	CFM, SP
